CE rohs,wind solar hybrid LED street lighting,vertical wind turbine,wind generator

FOB Reference Price:Get Latest Price
US $800-1,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Model Number:
winso60
Power Supply:
DC
Application:
Street
Lampshade Material:
Aluminium alloy
Lighting Bulbs & Tube:
LED
Supply Ability
Supply Ability:
2000 Set/Sets per Month
Packaging & Delivery
Packaging Details
plywood cartons
Port
ShangHai China
Lead Time :
15 days after deposit

Basic Configuration

Content

Type

Quantity

Remark

Solar Cell

60W

2pcs

CE certification

Wind Energy System

200W

1pcs

CE certification

LED light

30W

1pcs

CE certification

Energy Storage System

Lead-acid Battery

12V/200Ah

1pcs

CE certification

Controller

WWS03-300W

1pcs

CE certification

Special Cable



1set

CE certification

Lamp-post

Φ140mm

1set

Height : 5.5m

Battery Box

450(W)x(H)x610(D)



304 Stainless Steel



























Working principle

The product uses the solar cells which convert solar energy to electrical energy through photovoltaic effect and the wind-driven generator which convert the wind energy to electrical energy. The electrical energy is stored in the battery through the smart controller. When the illumination reduces to 10lux and the solar-cell open circuit voltage is lower than 4.5V, the batteries tart to discharge.

During the days with sunlight, electricity is generated from the solar cell. During the cloudy and rainy days, electricity is from the wind. Together with the solar and wind energy, the integrated system can provide 24-hour power to the light. The electricity can be stored by the battery unit and power the light through the controller at nights. The controller ensures the light working and data acquisition.



Specifications

Light Source: LED light

Voltage(V): DC10.5V-14.4V

Rated Power(W): 30W

Color Temp.(K): 5000-6500

Color Rendering: Ra>70

Luminous Flux: >2000 lm

Beam Angle(degree): 140°

Center Illumination: >15 lux

IP Grade: IP65

Solar Cell(W): 100W

Energy storage system: Lead-acid battery, 12V/200Ah

Continuous Service Days under Rainy Condition: 5days
